S104CPLUS

标准OPS整机

接纳Intel Raptor Lake-P 平台设计，搭载Intel Iris Xe Graphics 性能，参考标准OPS标准，可轻松装置、升级并维持，是聚会解决计划、教育和数字标牌应用的理想选择。

留言咨询营业咨询

规格参数

CPU	CPU	Intel? Raptor Lake-P Processor
CPU	TDP	28W
Display	Graphic card	Intel? Iris? Xe Graphics
	Multi displays	3 simultaneous 3 displays
	Interface	2 x HDMI1.4, 1 x 80PIN（1 x HDMI2.0 4K60Hz)
Network	Lan IC	1 x Realtek 8111H Co-Lay Intel Ethernet Connection I226LM
	Lan Interface	10/100/1000Mbps
	Lan Connector	1 x RJ45 Port
	Wireless Type	WIFI_BT module
	Wireless Interface	1 x M.2 2230 slot for WIFI_BT module
	4G/5G	Optional
I/O interface	Display	2 x HDMI1.4 (4K@30Hz) Or One Can chose HDMI IN ;
	USB	2* x USB3.0,2* x USB3.1 ,1 x Type-c(USB3.2 date )
	Button	1 x PowerButton, 1 x Clear CMOS Key
	Slot	1 x SIM Card Slot (Optional)
	AUDIO	1 x Line Out ; 1 x MIC-In
	POWER	1 x RJ45
	JAE	1 x 2.5/5.5 DC-IN Connector
System	Memory	Dual channel SO-DIMM DDR5-4800MHz MAX 32G
	Storage	1 x KeyM M.2 2280 NVMe/SATA SSD 1 x KeyB M.2 2242 SATA SSD
	OS	Windows11/Linux
	WatchDog	Support
	Auto Power On	Suppoer
	RTC	Support
	Power Input	12~19V DC IN, 2.5/5.5 DC Jack & JAE 80p
	Dimension	119mm(L) x 180mm(W) x 30mm(H)
	Operating Temp.	-5~45℃
	Operating Humidity	10%~90% non-condensing
	Storage Temp	-20~70℃
	Operating Humidity	10%~90% non-condensing
